The Concealed 2010 Series is a Heavy Duty Closer Designed to Provide Complete Concealment. The Single Lever Arm and Roller Assembly Provide Smooth, Quiet Door Control and the Choice of Finishes and Track Functions Meet Virtually All Architectural Requirements.
2011-BUMPER LH 691 LCN Door Closers and Operator
Regular Price $1,093.00 -43% Special Price $623.01
Availability: Available for Order
SKU
LCN2011BUMPERLH691
2011-BUMPER LH 691 LCN Door Closers and Operator is available to buy in increments of 1
Grade 1 Concealed Overhead Closer, Hydralic Slide Track In Header Mounting, Slide Track Arm, Standard with Bumper, 110 Deg. Swing, Adjustable Backcheck, Size 1, Light Bronze Powder Coat Finish, Left-Handed
Description
Speicfications
| Series | 2010 Series Concealed Closers |
|---|---|
| Vendor | Allegion |
| Manufacturer | LCN |
| ANSI | ANSI A156.4 |
| BAA Qualified | Yes |
| Grade | Grade 1 |
| Installation | Commercial |
| Limited Warranty | 15 Years |
| Finish Family | Matte Bronze |
| Arm Type | Slide Track Arm, Standard with Bumper |
| Back Check | Adjustable |
| Closer Size | 1 |
| Cover | No |
| Degree Swing | 110 Deg. |
| Handing | Left-Handed |
| Hold Open | No |
| Mounting Group | Hydraulic |
| Mounting Location | Header |
| Mounting Style | Slide Track |
| Screw Type | Machine and Wood |
| Type | Concealed Overhead |
| UL Listing | UL10C |
Details
The 2010 Series by LCN is a concealed heavy duty closer.
- Standard 2010 series closer shipped with standard arm, standard track, metal finish plate and wood and machine screw pack
- Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”
- Handed for right or left swinging doors
- For aluminum, hollow metal, or wood, doors and frames
- Aluminum frame requires minimum 4” x 4” (102 mm) tube
- Closers to meet ADA requirements
- Standard or optional custom powder coat finish
- Optional plated finish on arm, fasteners and finish plate
- Optional SRI primer for installations in corrosive conditions
The 2010 Series is designed to provide complete concealment. The single lever arm and roller assembly provide smooth, quiet door control and the choice of finishes and track functions meet virtually all architectural requirements.
