LCN Pneumatic Auto Equalizer Systems Use the Power of Pressurized Air to do the Work of Automatically Opening the Door. A Basic Pneumatic System Consists of an Automatic Operator to Provide the Door Control, a Control Box that Contains the Valves and Electrical Timing Circuits, Actuators to Start the System, And a Compressed Air Source.
2613-3971 RH 689 LCN Door Closers and Operator
Regular Price $2,500.00 -28% Special Price $1,795.50
Availability: Available for Order
SKU
LCN26133971RHAL
2613-3971 RH 689 LCN Door Closers and Operator is available to buy in increments of 1
2610 Series Auto Equalizer Pneumatic Cylinder with Door Position Sensor, Cylinder Only, Size 3, Aluminum Painted Finish, Right Handed
Description
Speicfications
| Series | 2610 Series Pneumatic Operators |
|---|---|
| Vendor | Allegion |
| Manufacturer | LCN |
| ANSI | ANSI A117.1, A156.19 |
| Grade | Grade 1 |
| Installation | Commercial |
| Limited Warranty | 2 Years |
| Finish Family | Matte Silver |
| Arm Type | Slide Track Arm, Standard |
| Closer Size | 3 |
| Cover | Less Cover |
| Degree Swing | 180 Deg. |
| Hold Open | No |
| Mounting Group | Pneumatic |
| Mounting Location | Header |
| Screw Type | Machine and Wood |
| Type | Concealed Overhead |
| UL Listing | UL228 |
Details
The 2610 Series is a low energy operator that provides easy access for people with disabilities.
- Ideal for multi-door applications since cost per door leaf decrease significantly as the number of door leaves increases.
- Standard 2610 series closer shipped with single lever (standard) arm, mounting/finish plate, standard track and wood and machine screw pack.
- Meets ADA requirements (power mode).
- Sized cylinders for interior doors to 4’0” and exterior doors to 3’0”.
- Handed for right or left swinging doors.
- Requires additional system components.
- Standard or optional custom powder coated finish.
- Optional plated finish on arm, fasteners, and mounting/finish plate.
The LCN 2610 Series is a pneumatically powered multi-door solution. It is designed primarily for manual opening applications that occasionally require automatic opening.
