The 4630 auto equalizer is LCN's smart and reliable electrically powered low-energy automatic operator. It provides easy access for people with disabilities, or the elderly. Designed primarily for manual opening applications that occasionally required automatic opening.
4630-141-2 689 LCN Door Closers and Operator
Regular Price $11.00 -48% Special Price $5.67
Availability: Available for Order
SKU
LCN46301412
4630-141-2 689 LCN Door Closers and Operator is available to buy in increments of 1
4630 Series Grade 1 Plug
Description
Specifications
| Series | 4630 Series Electrohydraulic Operators |
|---|---|
| Vendor | Allegion |
| Manufacturer | LCN |
| ANSI | A117.1, A156.19 |
| BAA Qualified | Yes |
| Grade | Grade 1 |
| Installation | Commercial |
| Limited Warranty | 2 Years |
| Origin | USA |
| UL Listing | UL 10C, UL 325/228 |
Details
The 4630 Series is a smart and reliable electrically low-energy power operator.
- Standard, top jamb (pull side) mounted 4630 series closer shipped with single lever (standard) arm, metal cover, standard track, and wood and machine screw pack. Actuators available separately, see pages 199-215 of the Catalog
- Meets ADA requirements (power mode).
- Non-sized cylinders for interior doors to 4’0” and exterior doors to 3’0”.
- Non-handed for either right or left swinging door.
- 4630 has easily accessible switches to provide on/off and continuous hold open functions. 4630CS provides concealed on/off power switch. Control module provides all timing and sequential door functions, electric strike controls and adjustments for opening speed and force.
- Standard or optional custom powder coated finish, end caps are black.
- Optional plated finish on cover, arm, and fasteners.
The 4630 Series has a digital control box and is designed for manual opening applications that occasionally require automatic opening. This series provides easy access for people with disabilities, the elderly, or the frail.
