Trilogy Narrow Stile lever models designed to work with Adams Rite latch series; Thumbturn models support swing & hook bolt products. Plus, PC-programmable 1300 Series models provide audit trail log of keyless entry door users.
DL1300/10B1 Alarm Lock Integrated and Pushbutton
Regular Price $1,348.59 -54% Special Price $619.27
Availability: Available for Order
SKU
ALA100DL130010B1
Pushbutton Aluminum Door Trim, 2000 Users, 40,000 Event Audit Trail, Straight Lever, Oil Rubbed Bronze
Description
Speicfications
| Series | DL1300 Narrow Stile Pin Locks |
|---|---|
| Vendor | Alarm Lock |
| Manufacturer | Alarm Lock |
| Users | 2000 |
| Base Material | Bronze |
| Grade | Grade 1 |
| Installation | Commercial |
| Limited Warranty | 2 Years |
| Finish Family | Dark Bronze |
| Cylinder Type | Mortise Cylinder |
| Keypad Type | Electronic |
| Lock Platform | Narrow Stile Mortise Keypad Trim |
| Door Thickness | 1-3/4" |
| Programmer | Optional |
| Reader Technology | Keypad Only |
| Series Name | Trilogy |
| Software | Optional |
Details
- Add keyless convenience to mechanical latch locks from Trilogy’s allmetal, vandal-resistant 12-button keypad and/or automatic timedscheduled locking/unlocking and audit trail with 1300 Series
- Aluminum door retrofit outside trim for Adams Rite® 1850, 1950, 4710, 4070*, 4730, 4900 Series and MS1850S* and MS1950S* Series latch locks
- DL1200 supports 100 3-5 digit PIN user codes, fingertip programmable
- DL1300 (and Prox PDL1300, right) support 2000 users, PC programming/reporting and features 40,000 event audit trail by user and 500 event schedule/real time clock (e.g. lock/unlock by time)
- Weatherproof -31˚ to +151˚F (-35˚ to +66˚C) • Long-life, battery-operated for 100,000 and 80,000 cycles respectively, typical on 2 lithium 3V batteries, supplied; low battery alert
- Compact styling 14-3/8”H x 1-5/8”D x 1-3/4”W
- Key override mortise cylinder, 1-1/4” supplied. (Supports 1-1/8”, 1-1/4” and 1-3/8”). Also interchangeable cores supported (Corbin/ Russwin, Yale, Schlage, Medeco.)
- Backsets 31/32”,1-1/8” and 1-1/2”; Stile thickness 1-3/4”
- Non-handed; fully field-reversible
- Two finishes US26D satin & 10B Durondic
Trilogy Narrow Stile lever models designed to work with Adams Rite® latch series; Thumbturn models support swing & hook bolt products. Plus, PC-programmable 1300 Series models provide audit trail log of keyless entry door users.
