The MLX Series is a robust Grade 2 lockset featuring a Free Wheeling Lever for abuse resistance, two screw lockset install for quick installation and a 10 Year Mechanical Warranty. The perfect solution for replacing or upgrading lockets in commercial applications.
MLX33-SR-26D-CS Arrow Locks, Cylinders, Cores, Keyblank
Regular Price $271.00 -61% Special Price $106.23
Availability: 26 available for order
SKU
ARRMLX33SR26DCS
MLX33-SR-26D-CS Arrow Locks, Cylinders, Cores, Keyblank is available to buy in increments of 1
Grade 2 Cylindrical Lock, Asylum Function, Dual Schlage C Keyway, Rigid Sierra Lever, 3-11/32" Rose Diameter, Removable Thru-Bolts, Satin Chrome Finish, Non-Handed
Description
Specifications
| Series | MLX Series Grade 2 Cylindrical Lever Locks |
|---|---|
| Vendor | ASSA Abloy |
| Manufacturer | Arrow |
| Color | Satin Chrome |
| ANSI | A156.2, Series 4000, Grade 2 |
| BAA Qualified | No |
| Fire Rating | 3 Hours {A} |
| Grade | Grade 2 |
| Installation | Commercial |
| Limited Warranty | 10 Years |
| Origin | South Korea |
| Finish Family | Matte Silver |
| Cylinder Type | Key-in-Knob / Key-in-Lever |
| Handing | Non-Handed |
| Lever/Knob Design Family | Straight Return Lever |
| Door Thickness | 1-3/8" - 1-3/4" |
| Function | 33-Asylum |
| Lock Face Size | 2-1/4" x 1-1/8" |
| Screws | Combination |
| Std. Strike Type | ANSI Strike |
| UL Listing | UL 10C |
Details
The MLX Series is the perfect solution for replacing or upgrading lockets in commercial applications.
- Door Preparation – Requires standard 2-1/8" (53.97mm) bore through door.
- Backset – 2-3/4" (69.85mm)
- Door Thickness – Fits 1-3/8" (34.93mm) to 1-3/4" (44.45mm) doors standard.
- Latch – Stainless Steel 1/2" (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions
- Latch Front – 1-1/8" x 2-1/4" for 2-3/4" (69.85mm) backset.
- Exposed Trim – MLX Levers are pressure cast zinc measuring 4-3/4" (120.65mm) in length. MLX Roses are wrought brass 3-11/32" (84.8mm) diameter. Total projection from face of door is 2-17/32" (64.5mm).
- Freewheeling Lever
- Warranty – Ten Year Warranty
- Handing – Non-handed
- Packaging – 6 per case
- Strike – 4-7/8" ANSI (123.83mm)
- Cylinder – Solid brass 6 pin, Arrow AR and Schlage CS Keyway, keyed different
- Keys – 2 brass keys
The MLX Series is a robust Grade 2 lockset featuring a FreeWheeling Lever for abuse resistance, two screw lockset install for quick installation and a 10 Year Mechanical Warranty.
