Bogen V150 Power Vector Amplifier 150W

Be the first to review this product

Special Price $564.66

Regular Price $1,063.22 -47%

Availability: Available for Order

SKU

BOG-V150

Notify me when the price drops

BOGEN COMMUNICATIONS BOG-V150 MODULAR, 8 INPUT, 150W, OUTPUT MODULE COMPATIBLE, METER

Bogen's Power Vector modular amplifiers offer a wide range of power levels from which to choose, with five

models from 35W to 250W. The amplifiers are designed to work with both high- (70/25V) and low- (4/8-ohm)

impedance speaker systems.

Each model includes eight module bays for plug-in input modules and allows up to four levels of priority

between modules. Two module bays are capable of accepting plug-in signal-processing output modules.

Each module is controlled by an independent volume control with an associated signal/clip LED for signal

status. An 11-segment LED output meter monitors output signal level.

Each model includes a motorized master volume control that can be controlled using a remote volume

control panel (RVCP, sold separately).

More Information
Manufacturer Part Number	V150
Features	• 5 models ranging from 35W to 250W each; a mixer-only version (VMIX) is also available • Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads • 8 module bays • Wide selection of advanced plug-in modules (modules sold separately) • 4 levels of priority between modules • 2 module bays capable of handling plug-in signal-processing output modules • 11-segment LED output level meter monitors the output level of the power amplifier with Avg./Peak meter switch • Motorized master volume control can be remotely operated • Lockable switch permits user to select either transformer-coupled outputs or a direct low-impedance output • 5-position barrier strip, with clamping washers, provides connections for speaker loads • Bridging In/Out connector • External access to priority mute buses • Bridging jack and Mute terminals join multiple Power Vector amps and mixers together • Independent volume control for each of the eight module bays • Two-color LED for each channel indicates input signal or clipping • Bass and treble control with bypass switch (located in module bay 6) • 125 Hz Low Cut switch (located in module bay 6) • Signal-processing insert jacks allow external equipment to be inserted between the pre-amp output and the power amp input • Pre-EQ, unbalanced, buffered output signal(“post” all unit controls, but “pre” any external “Insert” equipment connected) • Grounded, unswitched AC convenience receptacle with a 500W maximum capacity provided for external equipment • 8 module security cover/filler plates included with amplifier (PVMC) • Push-button remote volume control panel (Model RVCP, sold separately) • Security cover to selectively protect volume, bass, and treble controls (Model PVSC, sold separately) • Rack mountable (with rack mounting kit RPK87, sold separately) • 2 rack spaces high (3-1/2") • Listed to UL Standard 60065 for U.S. and Canada

• 5 models ranging from 35W to 250W each; a mixer-only version (VMIX) is also available

• Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads

• 8 module bays

• Wide selection of advanced plug-in modules (modules sold separately)

• 4 levels of priority between modules

• 2 module bays capable of handling plug-in signal-processing output modules

• 11-segment LED output level meter monitors the output level of the power amplifier with Avg./Peak meter switch

• Motorized master volume control can be remotely operated

• Lockable switch permits user to select either transformer-coupled outputs or a direct low-impedance output

• 5-position barrier strip, with clamping washers, provides connections for speaker loads

• Bridging In/Out connector

• External access to priority mute buses

• Bridging jack and Mute terminals join multiple Power Vector amps and mixers together

• Independent volume control for each of the eight module bays

• Two-color LED for each channel indicates input signal or clipping

• Bass and treble control with bypass switch (located in module bay 6)

• 125 Hz Low Cut switch (located in module bay 6)

• Signal-processing insert jacks allow external equipment to be inserted between the pre-amp output and the power amp input

• Pre-EQ, unbalanced, buffered output signal(“post” all unit controls, but “pre” any external “Insert” equipment connected)

• Grounded, unswitched AC convenience receptacle with a 500W maximum capacity provided for external equipment

• 8 module security cover/filler plates included with amplifier (PVMC)

• Push-button remote volume control panel (Model RVCP, sold separately)

• Security cover to selectively protect volume, bass, and treble controls (Model PVSC, sold separately)

• Rack mountable (with rack mounting kit RPK87, sold separately)

• 2 rack spaces high (3-1/2")

• Listed to UL Standard 60065 for U.S. and Canada
