Wireless display drivers are required to annunciate any wireless-specific events from the SWIFT® system. & They receive event information from the wireless network and then connect to a dedicated ANN-80-W for annunciation. All standard fire alarm events will report on the fire alarm control panel (FACP) just like a standard wired device. Any wireless-specific events (such as low battery), will annunciate a general trouble at the FACP and specific information on the ANN-80-W. Display & drivers are required when used with a MS-9600(UD)LS or MS-9200UDLS FACP but are not needed when used with an ES-200X and ES-50X FACP.
Wireless display drivers are required to annunciate any wireless-specific events from the SWIFT® system. & They receive event information from the wireless network and then connect to a dedicated ANN-80-W for annunciation. All standard fire alarm events will report on the fire alarm control panel (FACP) just like a standard wired device. Any wireless-specific events (such as low battery), will annunciate a general trouble at the FACP and specific information on the ANN-80-W. Display & drivers are required when used with a MS-9600(UD)LS or MS-9200UDLS FACP but are not needed when used with an ES-200X and ES-50X FACP.
More Information
Manufacturer Part Number
W-DIS-D
Features
Wireless mesh technology, 902 to 928 MHz frequency
Cascading-wave mesh operation provides a verification of redundant communication paths
Any wireless device can be added to act as a repeater
Each gateway supports up to 50 addresses: 1 wireless gateway, 1 display driver, and up to 49 devices
Up to & four wireless networks can be installed with overlapping radio network coverage
Site survey feature allows for an evaluation of a site before the installation
Standard code wheel for setting the SLC address
Wireless devices use four CR-123A lithium batteries
Write Your Own Review
Wireless mesh technology, 902 to 928 MHz frequency
Cascading-wave mesh operation provides a verification of redundant communication paths
Any wireless device can be added to act as a repeater
Each gateway supports up to 50 addresses: 1 wireless gateway, 1 display driver, and up to 49 devices
Up to & four wireless networks can be installed with overlapping radio network coverage
Site survey feature allows for an evaluation of a site before the installation
Standard code wheel for setting the SLC address
Wireless devices use four CR-123A lithium batteries
