The Air Products & Controls MR Series Multivoltage Control Relays offer SPDT or DPDT 10-amp contacts which may be operated by one of four input control voltages. A single relay may be energized from a voltage source of 24 VDC, 24 VAC, 115 VAC, or 230 VAC by wiring to appropriate input terminals.Each relay contains a red light-emitting diode (LED) which indicates the relay coil is energized. Relays may be "snapped apart" from a standard four-module assembly and used independently. These devices are ideal for applications where local contacts are required for system status, remote contacts for control of electrical loads and general purpose switching. They are suitable for use with HVAC, Temperature Control, Fire Alarm, Security, Energy Management, and Lighting Control Systems.
More Information
Manufacturer Part Number
MR-101/T
Features
Miscellaneous
Additional Information
Relays may be energized from a voltage source of 18 to 35VDC or VAC, 120VAC or 230VAC
Single, dual or triple relay modules may be snapped apart from standard 4-position master
Each relay position contains a red LED, which illuminates when the coil is energized
Single SPDT Relay with LED and track mounting hardware
DC control inputs are polarized
Compatibility
HVAC Systems
Temperature Control Systems
Fire Alarm Security Systems
Energy Management Systems
Lighting Control Systems
Physical Characteristics
Depth
1.5"
Height
3"
Width
2.1"
