The 7000 Series offers two solutions to address pre-loaded doors. The in-frame adjustable feature allows the installer to easily adjust the electric strike opening to accommodate the horizontal position of the latchbolt after installation. The pre-load release function allows the electric strike to operate smoothly throughout the year under varying loads on the door caused by air-conditioning pressure, changes in the weather, warped doors or doors with weather stripping that often bind standard electric strikes. This unit accommodates cylindrical latchbolts up to 5/8" throw and rim exit latchbolts up to 3/4" throw.
7000 HES Electric Strikes, Bolts, Magnet
Regular Price $365.00 -51% Special Price $179.87
Availability: Available for Order
SKU
HAN1007000
Electric Strike Body Only, Fail Safe/Fail Secure, 12/24VDC
Description
Specifications
| Series | 7000 Series Electric Strikes |
|---|---|
| Vendor | ASSA Abloy |
| Manufacturer | HES |
| BAA Qualified | Yes |
| Grade | Grade 1 |
| Installation | Commercial |
| Limited Warranty | 3 Years |
| Origin | USA |
| Configuration | Centered |
| For Use With | Cylindrical Locks |
| Frame Application | Metal or Wood |
| Keeper Size | 1/2" |
| AMP Draw | .45 Amps @ 12VDC, .25 Amps @ 24VDC |
| Function | Fail Safe/Fail Secure |
| Operating Voltage | 12/24 VDC |
Details
The 7000 Series has both an in-frame adjustable feature as well as a pre-load release function.
UL 1034, burglary-resistant listed
ANSI/BHMA A156.31, Grade 1 (791 and 792 options)
ANSI/BHMA A156.31, Grade 2 (783S, 786S and 789S options)
MEA New York City accepted
Patent #5,484,180
The 7000 Series offers two solutions to address pre-loaded doors. This unit accommodates cylindrical latchbolts up to 5/8" throw and rim exit latchbolts up to 3/4" throw.
