NXT-4D-MSC Keri Systems Access Control

The NXT-4D Controller is built for today's IT environments. By using an existing TCP/IP network, controller cabling costs can be eliminated. Or, if building a new network, they can be reduced up to 50% over traditional hard-wired access systems by using inexpensive, shielded CAT-5 cable. The NXT-4D is designed to be extremely intelligent with little reliance on network tra c for decision making, allowing it to be thrifty with any network's valuable bandwidth. With Ethernet functionality built directly into the controller. Keri's propriatary MAC addressing scheme allows for reliable hardware discovery and true one-button autocon guration. To expand the system's capabilities, up to four companion 4X4 Input/Output boards (NXT-4X4) can be added - one to each of the controller's RS-485 trunks (buses). Customers can choose between Keri's line of highly secure, 4-wire NXT Series Proximity Readers with reader supervision that also provide In/Out reading capaiblity (8 readers), or any reader with a standard Wiegand output or Keri's MS Series Proximity Readers via the NXT-RM3 Reader Interface Module. To manage the system, Doors.NET software has much of the same look and feel as Keri's acclaimed original DoorsTM software, but with the added functionality of a Client/Server architecture. Keri Systems has partnered with Mercury Security to bring enhanced capabilities to its Doors.NET customers that use the NXT hardware platform of TCP/IP-based controllers. Standard rmware NXT Controllers provide all the functionality needed for a typical access control system and, along with some basic I/O linking capability, excellent manual system control, great reporting capability, integrated video and more. For applications that require more specialized or sophisticated features, NXT Controllers are available with Mercury rmware to provide a higher level of functionality than standard NXT controllers.
