RLBD Schlage Electronics Integrated and Pushbutton

AD-400 locks feature upgradeable credential reader modules and real-time integration with most access control system.

Security

• Electronic access control brings more visibility and control to the opening
• Modular design allows reader upgrade to fit changing credential needs without changing the lock
• Real-time communication with centralized lockdown capability
• Unique communication protocols that has a longer range and won’t interfere with other wireless networks
• Secure encrypted data transmission
• Weather-resistant for interior and perimeter applications

Efficiency

• Open architecture platform is compatible with most major access control systems
• Flexible connectivity options to fit building infrastructure

Convenience

• Integrated design combines electrified lock, credential reader, request-to-exit and request-to-enter sensors, door position switch and tamper switch
• Smart credentials can be used for vending and other applications
• Non-invasive installation

AD Series locks were designed to be adaptable, allowing upgrades to be made to new technologies without taking the lock off the door. They integrate into popular electronic access control systems from Software Alliance Members to deliver a comprehensive EAC solution.

Available in cylindrical, mortise, mortise deadbolt and exit trim chassis options, they feature built-in credential reader and access control sensors for simplified installation.

The AD-400 enables a wide range of credential options including NFC mobile, smart (13.56 MHz), proximity (125 kHz),  magnetic stripe and PIN credentials; card + PIN is also available for extra security.

AD-400 locks communicate using 900 MHz wireless technology to the PIM400, operating independently of the IT network. For real-time connectivity and lockdown, the PIM400 is wired to the access control panel (ACP) either by Wiegand or RS-485. AD-400 wireless locks can work in the same access control system as other wireless devices including Schlage NDE, LE, and the WRI400. Features and capabilities will vary by system; please see the Software Alliance Members tab for additional details.
