The LM Series interfaces with an access control or alarm system to indicate the state of the latchbolt. Used alone or in conjunction with a door position switch, the LM provides confirmation that the door is secure, preventing false alarms and unauthorized access while providing tamper detection. Can also be used to transmit an initiate signal to model XDT delayed egress logic timers. Installs easily, conceals behind existing hardware. Requires no jamb or strike plate modification.
LML-1 Securitron Electric Strikes, Bolts, Magnet
Regular Price $170.00 -46% Special Price $91.39
Availability: Available for Order
SKU
SEC100LML1
Strike with Latch Monitor, 4-7/8" ANSI Faceplate, Satin Chrome
Description
Specifications
| Series | Securitron LM Latch Monitors |
|---|---|
| Vendor | ASSA Abloy |
| Manufacturer | SECURITRON |
| ANSI | 294 |
| BAA Qualified | Yes |
| Base Material | Steel |
| Fire Rating | No |
| Installation | Commercial |
| Limited Warranty | Lifetime |
| Origin | USA |
| Finish Family | Matte Silver |
| UL Listing | 634 |
Details
The LM Series is designed for reporting back to an alarm system to indicate that a door is latched, reducing the possibility of false alarms.
Product Features
- Electronically verify mechanical latch and bolt positions
- Detect and report that a door is actually latched or bolted, not just closed
- Installs easily concealed behind existing hardware
- Requires no jamb or strike plate modification
- LMS-1 includes a single SPDT switch and fits any standard 2-3/4" ANSI cutout
- LML-1 also has a single SPDT switch and fits any standard 4-7/8" ANSI cutout
- LML-2 monitors a mortise latch and deadbolt separately, has two separate SPDT switches, and fits any standard 4-7/8" ANSI cutout
- UL Listed
- MagnaCare® lifetime replacement, no fault warranty
Specification Data
- Contact Rating:SPDT 2 Amp at 24V
- Operating Temperature: -40 to +160F [-40 to +71C]
Can also be used to provide an initiate signal to model XDT delayed egress logic timers.
