AXC-02968001

AXIS Q1686-DLE Radar-Video Fusion Camera. Speed and license plate pairing camera by utilizing fusion of visual- and radar sensor information in one device and on edge. Powerful device for wrong way applications and directional alerts by radar technology. 1/1.8 image sensor, outdoor, NEMA 4X, IP66, IP67 and impact-resistant, 4 MP, Day/night radar-video fusion camera with Deep Learning Processing Unit (DLPU). Image optimization for license plate capture profile, traffic capture profile and Lightfinder 2.0. OptimizedIR, a purpose built and powerful 850nm IR-illuminator kit. Includes an varifocal 9-50 mm F1.5 i-CS lens with remote zoom and focus. Integrated radar unit, 60.0 GHz-61.5 GHz and 95 degree horizontal field of detection. In addition to radar-video fusion, radar functionality such as built-in analytics including classification of vehicles, is available and enables filtering on distance, customized detection zones, and multiple line crossing. Multiple, individually configurable streams, H.264/H.265 with Zipstream and Motion JPEG. 4MP stream up to 60 fps, 30 fps with WDR. Radar motion detection, AXIS Speed Monitor, shock detection and active tampering alarm. Axis Edge Vault with FIPS certified TPM for added cyber security. Barrel distortion correction, defogging, electronic image stabilization, electronic radar stabilization and scene profiles. MQTT Support. Two-way audio, audio detection with optional analog or digital microphone. Supervised I/O for alarm/event handling, MicroSD/MicroSDHC memory card slot for optional local video storage. Serial port for RS422/485 communication. Powered by IEEE 802.3at Type2 Class 4 (PoE+) or 10-28 V DC power with redundancy. Built-in heater, Arctic Temperature Control for start-up in -40 C to +60 C (-40 F to 140 F). Includes removable sunshield, wall bracket, Torx T20 screwdriver and cable glands. Midspan or power supply not included. Radio approvals, EN 300440, EN 301489-1, EN 301489-51, EN 62311, FCC Part 15 Subpart C.
