The MA series is one of Falcon's toughest, most dependable locks. It delivers high performance at an affordable cost for your office, education, healthcare, multi-family and other commercial needs. The MA series products make retrofits easy with the ability to be rehanded in the field without opening the mortise case. With BHMA Grade 1 Security, BHMA Grade 1 Operational along with UL 3 hour ratings, the MA Series is designed to meet your needs.
More Information
Manufacturer Part Number
MA521B QG 626
Features
Door thickness:Standard accommodates thickness of 1-3/8to 2-1/2?.
Backset:2-3/4only.
Case:Cold formed steel, zinc dichromate plated, .090thick.
Hubs:Hardened steel.
Handing:Right hand is standard; left hand optional. Reversible in the field.
Cylinders:Solid brass cylinder and plug.Standard mortise cylinders are furnished as 5-or 6-pin as standard. 6 or 7-pin are available on interchangeable core cylinder.
Furnished with two nickel silver keys standard
Keyways:Gkeyway standard on standard cylinder.A? keyway standard on I/C cylinder.
Bind Resistant Trim:Heavy-duty through-bolted inserts clamp the trim on the door assuring proper alignment. Provided with 8-32 screws for strength and thread sealant to prevent loosening.
Dead Bolt:1throw, stainless steel with two 13/16diameter hardened steel, free-turning, saw-resistant roller.
Faceplates:(Armored Front) 1-1/4x 8brass or stainless steel adjustable for door bevel. Reinforced by heavy gauge steel with stabilizing ribs.
Strike:Brass or stainless steel. Meets ANSI AII5.1 for frame preparation. Strike is non-handed.
Electrified Functions:Available in 12 or 24 VDC. ANSI/BHMA: Meets ANSI/BHMA 156.13, Series 1000.
UL:3 hour A label.
