Nominal Capacity 20-hr. (600mA to 10.50 volts) ....................................................... 12.0 AH 10-hr. (1.1A to 10.50 volts) ............................................................ 11.0 AH 5-hr. (2.1A to 10.20 volts) ............................................................ 10.5 AH 1-hr. (7.25A to 9.00 volts) ............................................................. 7.25 AH 15-min. (21.5A to 9.00 volts) .............................................................. 5.38 AH Approximate Weight ........................................................... 7.92 lbs. (3.59 kg) Energy Density (20-hr. rate) ............................... 1.69 W-h/in3 (103.41 W-h/l) Specifi c Energy (20-hr. rate) .............................. 18.18 W-h/lb (40.08 W-h/kg) Internal Resistance (approx.) ...................................................... 20 milliohms Max Discharge Current (7 Min.) ............................................... 36.0 amperes Max Short-Duration Discharge Current (10 Sec.) ................ 120.0 amperes Shelf Life (% of nominal capacity at 68°F (20°C)) 1 Month ...................................................................................................... 97% 3 Months ..................................................................................................... 91% 6 Months .................................................................................................... 83%
Absorbent Glass Mat (AGM) technology for superior performance Valve regulated, spill proof construction allows safe operation in any position Power/volume ratio yielding unrivaled energy density Rugged impact resistant ABS case and cover (UL94-HB) Approved for transport by air. D.O.T., I.A.T.A., F.A.A. and C.A.B. certifi ed U.L. recognized under fi le number MH 20845
Write Your Own Review
Specifications
Nominal Capacity 20-hr. (600mA to 10.50 volts) ....................................................... 12.0 AH 10-hr. (1.1A to 10.50 volts) ............................................................ 11.0 AH 5-hr. (2.1A to 10.20 volts) ............................................................ 10.5 AH 1-hr. (7.25A to 9.00 volts) ............................................................. 7.25 AH 15-min. (21.5A to 9.00 volts) .............................................................. 5.38 AH Approximate Weight ........................................................... 7.92 lbs. (3.59 kg) Energy Density (20-hr. rate) ............................... 1.69 W-h/in3 (103.41 W-h/l) Specifi c Energy (20-hr. rate) .............................. 18.18 W-h/lb (40.08 W-h/kg) Internal Resistance (approx.) ...................................................... 20 milliohms Max Discharge Current (7 Min.) ............................................... 36.0 amperes Max Short-Duration Discharge Current (10 Sec.) ................ 120.0 amperes Shelf Life (% of nominal capacity at 68°F (20°C)) 1 Month ...................................................................................................... 97% 3 Months ..................................................................................................... 91% 6 Months .................................................................................................... 83%
Absorbent Glass Mat (AGM) technology for superior performance Valve regulated, spill proof construction allows safe operation in any position Power/volume ratio yielding unrivaled energy density Rugged impact resistant ABS case and cover (UL94-HB) Approved for transport by air. D.O.T., I.A.T.A., F.A.A. and C.A.B. certifi ed U.L. recognized under fi le number MH 20845
