A53PD ORB 626 E Keyway
A53PD ORB 626 E Keyway
Special Price $169.25
Regular Price $315.00 -46% Availability: Available for Order
SKU A53PD ORB 626 E Keyway
A53PD ORB 626 E Keyway
Grade 2 Entrance Cylindrical Lock, Orbit Knob, Conventional Cylinder, Satin Chrome Finish, Non-handed
Schlage
A53PD ORB 626
Grade 2 Entrance Cylindrical Lock, Orbit Knob, Conventional Cylinder, Satin Chrome Finish, Non-handed
More Information Manufacturer Part Number | A53PD ORB 626 E Keyway |
Features | Product Specs
Vendor
Allegion
Manufacturer
Schlage
SKU
A53PD ORB 626
UID
SCH100A53PDORB626
Grade
Grade 2
Installation
Commercial
Origin
Mexico
Unit of Measure
Each
Base Material
Brass, Bronze
UL Listing Type
ANSI A156.2-2011, Series 4000, Grade 2, UL Listed
ANSI Number
F109
Limited Warranty
3 Year Warranty
Fire Rated
3 Hours {A}
Burglar Rated
No
Finish
Finish
626/US26D
Finish Description
Satin Chrome
Finish Family
Matte Silver
Technical Specs
Function
53-Entrance Lock
Function Family
Entrance
ANSI Function
F109 - Entry/Office
Lever/Knob Design
ORB - Orbit Knob
Lever/Knob Design Family
Ball Knob
Rose/Escutcheon Design
2-9/16" Rose Diameter
Rose/Escutcheon Dimensions
2-9/16"
Cylinder Type
Conventional Cylinder
Num Pins
6
Key(s)
Cut
Num of Keys
2
Handing
Non-handed
Door Thickness
1-3/8" to 1-7/8"
Std. Latch Number
11-085
Std. Latch Type
Deadlatch
Std. Latch Backset Dim
2-3/8"
Latch Bore Diameter
7/8"
Lock Face Size
1" x 2-1/4"
Bolt Projection
1/2"
Bore Hole Diameter
2-1/8"
Std. Strike Number
10-001
Std. Strike Type
T-Strike
Std. Strike Height
2-3/4"
Std. Strike Width
1-1/8"
Dust Box
Plastic
Screws
Wood/Metal Screws
Product Type
Cylindrical Lock
Dimensions
Product
Product Length
9.5"
Product Width
8.25"
Product Height
4.75"
Package
Package Length
9.5"
Package Width
8.25"
Package Height
4.75"
Package Volume
372.28
Package Qty
1 |
---|
Product Specs
Vendor
Allegion
Manufacturer
Schlage
SKU
A53PD ORB 626
UID
SCH100A53PDORB626
Grade
Grade 2
Installation
Commercial
Origin
Mexico
Unit of Measure
Each
Base Material
Brass, Bronze
UL Listing Type
ANSI A156.2-2011, Series 4000, Grade 2, UL Listed
ANSI Number
F109
Limited Warranty
3 Year Warranty
Fire Rated
3 Hours {A}
Burglar Rated
No
Finish
Finish
626/US26D
Finish Description
Satin Chrome
Finish Family
Matte Silver
Technical Specs
Function
53-Entrance Lock
Function Family
Entrance
ANSI Function
F109 - Entry/Office
Lever/Knob Design
ORB - Orbit Knob
Lever/Knob Design Family
Ball Knob
Rose/Escutcheon Design
2-9/16" Rose Diameter
Rose/Escutcheon Dimensions
2-9/16"
Cylinder Type
Conventional Cylinder
Num Pins
6
Key(s)
Cut
Num of Keys
2
Handing
Non-handed
Door Thickness
1-3/8" to 1-7/8"
Std. Latch Number
11-085
Std. Latch Type
Deadlatch
Std. Latch Backset Dim
2-3/8"
Latch Bore Diameter
7/8"
Lock Face Size
1" x 2-1/4"
Bolt Projection
1/2"
Bore Hole Diameter
2-1/8"
Std. Strike Number
10-001
Std. Strike Type
T-Strike
Std. Strike Height
2-3/4"
Std. Strike Width
1-1/8"
Dust Box
Plastic
Screws
Wood/Metal Screws
Product Type
Cylindrical Lock
Dimensions
Product
Product Length
9.5"
Product Width
8.25"
Product Height
4.75"
Package
Package Length
9.5"
Package Width
8.25"
Package Height
4.75"
Package Volume
372.28
Package Qty
1
