Securitron M62BD

The M62 is a strong, easy-to-maintain solution for interior, perimeter and exterior access control. With unsurpassed durability, the M62 will last long after most buildings wear out. Flexible mounting options support applications for hollow metal, concrete filled metal, wood, or glass with aluminum frames, and Herculite doors. Options include single and double door configurations, or specialty applications such as gates and fences. Ultra-secure collapsing blind nuts mount to door frame for strength and reliability. Fully sealed for weatherproof operations. 10 ft. [3.05m] of jacketed, stranded conductor cable. Automatic dual-voltage. Instant release circuit with no residual magnetism. Noise suppression with included MOV. Efficient, low power usage. Rust resistant with all ferrous metal surfaces plated for durability. Fits in 2.5" of flat mounting space. 1,200 lbs. [544kg] holding force. Dimensions: Magnalock: 8"L x 1-3/4"D x 3"H, Strike: 6"L x 1/2"D x 2-3/4"H. Electrical: 250 mA at 12 VDC, 150 mA at 24 VDC. Operating Temperature: -40 to +140F [-40 to +60C], indoor or outdoor use.

Maglock, 1200lb Holding Force, Magnetic Bond Sensor, Door Position Switch, 12/24VDC, Satin Stainless Steel
