Securitron M680EBD

The M680 from Securitron delivers unsurpassed intelligence, style and convenience. A built-in, smart voltage sensing microprocessor controls Securitron's patented BondSTAT and door position status monitoring. The aesthetics of the M680 are refined enough for the most discriminating designer openings. An integrated camera option provides a unique perspective for discreet surveillance and clear facial views. The fastest, easiest, most secure installation of any bracket-mount maglock. Innovative install templating for an effortlessly accurate alignment between magnet and armature plate. Sleek, low profile and refined lines for improved aesthetics. LED visual locked status with configurable red/green color output. BondSTAT lock bond sensor. Integrated door position switch. Autosensing dual-voltage with microprocessor technology. Adjustable automatic relock timer (0 to 30 seconds). Wire chamber anti-tamper switch. Efficient, low power usage. Size optimized for use with door closers. Holding Force: 1,100 lbs [499 kg]. Dimensions: M680BD Magnalock: 11-1/2"L x 2-9/16"D x 2-1/2"H, Strike: 10-7/8"L x 9/16"D x 2"H. Electrical: 550 mA (� 10%) at 12 VDC300 mA (� 10%) at 24 VDC. Operating Temperature: +32 to +110F [0 to +43C]. Indoor use only. Maglock, 1100lb Holding Force, Magnetic Bond Sensor, Door Position Switch, 12/24VDC, Satin Aluminum Clear Anodized
