The SD505-DUCTR Addressable duct smoke detector provides early detection of smoke and products of combustion present in air moving through an HVAC duct to prevent re-circulation of smoke into the air handling system. The SD505-DUCTR is a heavy duty metal housing with a pre-installed SD505-APS Analog Photo Electric Smoke Sensor and relay module. When smoke is detected in a duct, the unit communicates the condition to the IntelliKnight FACP. The built-in relay module, in turn, turns off fans, blowers, and other devices. The SD505-DTS-K is a remote switch that is used with the SD505-DUCTR so you can remote test the Duct Detector. It also provides LED indication of the status of the SD505-DUCTR. The SD505-DTS-K uses the same key as the control panel.
More Information
Manufacturer Part Number
SD505-DTS-K
Features
• Two-wire connection to SLC • Detects and limits spread of smoke • LED alarm indication and communication on sensor head • Rugged steel backbox with clear plastic cover • Installation template included • No screens or filters to clean • SD505-APS Photoelectric Smoke Detector pre-installed • 3 standard tube lengths • UL listed, complies with NFPA 72 and 101 • CSFM listed • MEA Approved 429-92-E, Vol 9 • FM Approved
Write Your Own Review
• Two-wire connection to SLC • Detects and limits spread of smoke • LED alarm indication and communication on sensor head • Rugged steel backbox with clear plastic cover • Installation template included • No screens or filters to clean • SD505-APS Photoelectric Smoke Detector pre-installed • 3 standard tube lengths • UL listed, complies with NFPA 72 and 101 • CSFM listed • MEA Approved 429-92-E, Vol 9 • FM Approved
