Trine 30RS 3000 Series Electric Strike Body
| Manufacturer Part Number | 30RS |
|---|---|
| Features | Trine 30RS Electric Strike - Body Only - Fail Safe -11-29 AC/DC LC-100 Included: Line Condition (LC100) which allows 11 thru 29 AC/DC Voltage input - with surge and kickback protection and continuous duty Designed so a 1" drill bit can be used to hide unit in wood. can be used on the 30LC & 30RS ONLY andplaced up to 15’ feet away! Mechanism Features: Continuous Duty GRADE 1 500,000 + life cycles 1,500 + lbs. holding force (1,200 lbs. for 334) Dynamic Force 70 ft/lb. Solid stainless steel latch and in the device body. Accepts a bolt with a up to 5/8" throw Non-handed Unit (except 458, 478 LO/RO) Fail safe - “RS" (locks with power) Mechanism spacers increase cavity depth up to 1/8" Specifications: BHMA - A156.31, 2001 BHMA Grade 1 - All models (except 334) BHMA Grade 2 - 334 |
Trine 30RS Electric Strike - Body Only - Fail Safe -11-29 AC/DC
LC-100 Included:
Line Condition (LC100) which allows 11 thru 29 AC/DC Voltage input - with surge and kickback protection and continuous duty
Designed so a 1" drill bit can be used to hide unit in wood.
can be used on the 30LC & 30RS ONLY andplaced up to 15’ feet away!
Mechanism Features:
Continuous Duty
GRADE 1
500,000 + life cycles
1,500 + lbs. holding force (1,200 lbs. for 334)
Dynamic Force 70 ft/lb.
Solid stainless steel latch and in the device body.
Accepts a bolt with a up to 5/8" throw
Non-handed Unit (except 458, 478 LO/RO)
Fail safe - “RS" (locks with power)
Mechanism spacers increase cavity depth up to 1/8"
Specifications:
BHMA - A156.31, 2001
BHMA Grade 1 - All models (except 334)
BHMA Grade 2 - 334
